Features
- High short-circuit withstand capability (SCWC)
- 100% UIS tested in production
- Low switching losses, QSW and EOSS
Applications
- Motor Control
- Battery disconnect switch
- Switch mode power supply on primary and secondary
| Parameter TA = 25°C unless otherwise noted | Value | Unit |
|---|---|---|
| VDS | 200 | V |
| RDS(on) max | 25 | mΩ |
| ID | 40 | A |
| IDM | 154 | A |
| QG | 26.5 | nC |
| QSW | 2.7 | nC |
| EOSS | 1 | μJ |
| VGS | ± 20 | V |
| VGS(th) | 3.6 | V |
| PD | 100 | W |
| TJ,Tstg | -55 to 175 | °C |
| EAS | 159 | mJ |
| RθJC | 1.5 | °C/W |
