Features
• Low on-resistance, RDS(on)
• Robustness under fault conditions, including high short-circuit withstand current (SCWC)
• Optimized QSW and EOSS for hard switching
• 175°C temperature rating
Applications
- Motor control
- Battery disconnect switch
- Switch mode power on primary and secondary side
| Parameter TA = 25°C unless otherwise noted | Value | Unit |
|---|---|---|
| VDS | 150 | V |
| RDS(on) max | 2.5 | mΩ |
| ID | 235 | A |
| IDM | 854 | A |
| QG | 135 | nC |
| QSW | 8.7 | nC |
| EOSS | 2.7 | μJ |
| VGS | ± 20 | V |
| VGS(th) | 3.2 | V |
| PD | 314 | W |
| TJ,Tstg | -55 to 175 | °C |
| EAS | 1087 | mJ |
| RθJC | 0.48 | °C/W |
