Features
• Low on-resistance, RDS(on)
• Ultra-low energy stored, EOSS
• Ultra-low turn-off energy, EOFF
• Optimized QSW for hard switching
• Low reverse recovery time trr and Qrr
Applications
- Boost converters and SMPS control FETs
- Secondary side synchronous rectifier
- Motor control
| Parameter TA = 25°C unless otherwise noted | Value | Unit |
|---|---|---|
| VDS | 150 | V |
| RDS(on) max | 8.8 | mΩ |
| ID | 88 | A |
| IDM | 351 | A |
| QG | 36 | nC |
| QSW | 3.6 | nC |
| EOSS | 0.7 | μJ |
| VGS | ± 20 | V |
| VGS(th) | 3.3 | V |
| PD | 150 | W |
| TJ,Tstg | -55 to 175 | °C |
| EAS | 350 | mJ |
| RθJC | 1 | °C/W |
