Features
特性
• 广泛的SOA和电流处理能力
• 故障条件下的鲁棒性
• 量产产品均通过100% UIS测试
• 低开关损耗，QSW和EOSS
• 栅极阈值±0.5V，并联更便捷
Applications
应用
• 电机控制
• 升压转换器和开关模式电源（SMPS）控制场效应管（FET）
• 二次侧同步整流器
• D类音频
| Parameter TA = 25°C unless otherwise noted | Value | Unit |
|---|---|---|
| VDS | 200 | V |
| RDS(on) max | 25 | mΩ |
| ID | 40 | A |
| IDM | 154 | A |
| QG | 26 | nC |
| QSW | 2.7 | nC |
| EOSS | 1.0 | μJ |
| VGS | ± 20 | V |
| VGS(th) | 3.6 | V |
| PD | 100 | W |
| TJ,Tstg | -55 to 175 | °C |
| EAS | 159 | mJ |
| RθJC | 1.5 | °C/W |
